Practical homerow mouse keys

Cut to the code

Introduction

Easy

Introduction

Some people don’t have a mouse (in third world countries) or they don’t want to move there hand all the way to the mouse. this is a better alternative to the regular numpad mouse keys solution provided by DEs (Desktop Environments). You can see the advantages of these mouse keys over the standard below

Pros & Cons over the standard

Pros

  1. Controlled from the homerow, thus improving productivity
  2. Different speed modifiers, Shift for slow, Ctrl for fast
  3. Scroll using the superkey (Correct me if i’m wrong, but I didn’t see that feature in the solutions provided by DEs)
  4. Press left click and middle click without a toggle (to press left click and middle click in mouse keys provided by DE you have to press a toggle first which will turn the right click into left click)

Cons

  1. You have to press super+m to enter mouse mode to control the mouse

Testament for the practicality

I have used these mousekeys for a long time to design posts in inkscape, here is what I was able to design using these mouse-keys

Islamic poster designs islamic poster designs

Code

The code is in sway, and ydotool is used to control the mouse, for X11 you can use xdotool.

sway config

mode " mouse" {
    ## IMPORTANT! Keybinding to escape mousemode
    ## Modifying repeat_delay back to what it was
    bindsym $mod+m input 'type:keyboard' repeat_delay 300, mode "default"

    set $min_slow 2
    set $max_slow 10
    set $slow_accelration 1

    set $min_average 5
    set $max_average 30
    set $average_accelration 4

    set $min_fast 10
    set $max_fast 60
    set $fast_accelration 6

    set $accelrate_script /home/taham/.config/sway/scripts/accelrate.sh
    set $speed_path /home/taham/.config/sway/data/speed

    ## Clicks
    bindsym u exec ydotool click 0x40
    bindsym --release u exec ydotool click 0x80
    bindsym i exec ydotool click 0x41
    bindsym --release i exec ydotool click 0x81
    bindsym m exec ydotool click 0x42
    bindsym --release m exec ydotool click 0x82


    # This is neccesary or otherwise you can't shift / ctrl click, cause on pressing shift you can't click
    # I have not implemented (Alt is Mod1) Shift+Alt, Ctrl+Alt, Shift+Ctrl+Alt, you can implement them if you need them
    bindsym Shift+u exec ydotool click 0x40
    bindsym --release Shift+u exec ydotool click 0x80
    bindsym Shift+i exec ydotool click 0x41
    bindsym --release Shift+i exec ydotool click 0x81
    bindsym Shift+m exec ydotool click 0x42
    bindsym --release Shift+m exec ydotool click 0x82

    bindsym Ctrl+u exec ydotool click 0x40
    bindsym --release Ctrl+u exec ydotool click 0x80
    bindsym Ctrl+i exec ydotool click 0x41
    bindsym --release Ctrl+i exec ydotool click 0x81
    bindsym Ctrl+m exec ydotool click 0x42
    bindsym --release Ctrl+m exec ydotool click 0x82

    bindsym Ctrl+Shift+u exec ydotool click 0x40
    bindsym --release Ctrl+Shift+u exec ydotool click 0x80
    bindsym Ctrl+Shift+i exec ydotool click 0x41
    bindsym --release Ctrl+Shift+i exec ydotool click 0x81
    bindsym Ctrl+Shift+m exec ydotool click 0x42
    bindsym --release Ctrl+Shift+m exec ydotool click 0x82

    # Mod1 is alt
    bindsym Mod1+u exec ydotool click 0x40
    bindsym --release Alt+u exec ydotool click 0x80
    bindsym Mod1+i exec ydotool click 0x41
    bindsym --release Alt+i exec ydotool click 0x81
    bindsym Mod1+m exec ydotool click 0x42
    bindsym --release Alt+m exec ydotool click 0x82

    ## Average speed movement
    # bindsym h exec ydotool mousemove -x -$average -y 0
    bindsym h exec "$accelrate_script $max_average $average_accelration; read speed < $speed_path; ydotool mousemove -x -$speed  -y 0"
    bindsym --release h exec echo $min_average > $speed_path
    bindsym j exec "$accelrate_script $max_average $average_accelration; read speed < $speed_path; ydotool mousemove -x 0 -y $speed"
    bindsym --release j exec echo $min_average > $speed_path
    bindsym k exec "$accelrate_script $max_average $average_accelration; read speed < $speed_path; ydotool mousemove -x 0 -y -$speed"
    bindsym --release k exec echo $min_average > $speed_path
    bindsym l exec "$accelrate_script $max_average $average_accelration; read speed < $speed_path; ydotool mousemove -x $speed  -y 0"
    bindsym --release l exec echo $min_average > $speed_path
    ## Diagnol movements
    bindsym n exec "$accelrate_script $max_average $average_accelration; read speed < $speed_path; ydotool mousemove -x -$speed  -y $speed"
    bindsym --release n exec echo $min_average > $speed_path
    bindsym Period exec "$accelrate_script $max_average $average_accelration; read speed < $speed_path; ydotool mousemove -x $speed  -y $speed"
    bindsym --release Period exec echo $min_average > $speed_path
    bindsym y exec "$accelrate_script $max_average $average_accelration; read speed < $speed_path; ydotool mousemove -x -$speed  -y -$speed"
    bindsym --release y exec echo $min_average > $speed_path
    bindsym o exec "$accelrate_script $max_average $average_accelration; read speed < $speed_path; ydotool mousemove -x $speed  -y -$speed"
    bindsym --release o exec echo $min_average > $speed_path

    ## Slow movements
    bindsym Shift+h exec "$accelrate_script $max_slow $slow_accelration; read speed < $speed_path; ydotool mousemove -x -$speed  -y 0"
    bindsym --release Shift+h exec echo $min_slow > $speed_path
    bindsym Shift+j exec "$accelrate_script $max_slow $slow_accelration; read speed < $speed_path; ydotool mousemove -x 0 -y $speed"
    bindsym --release Shift+j exec echo $min_slow > $speed_path
    bindsym Shift+k exec "$accelrate_script $max_slow $slow_accelration; read speed < $speed_path; ydotool mousemove -x 0 -y -$speed"
    bindsym --release Shift+k exec echo $min_slow > $speed_path
    bindsym Shift+l exec "$accelrate_script $max_slow $slow_accelration; read speed < $speed_path; ydotool mousemove -x $speed  -y 0"
    bindsym --release Shift+l exec echo $min_slow > $speed_path
    bindsym Shift+n exec "$accelrate_script $max_slow $slow_accelration; read speed < $speed_path; ydotool mousemove -x -$speed  -y $speed"
    bindsym --release Shift+n exec echo $min_slow > $speed_path
    bindsym Shift+Period exec "$accelrate_script $max_slow $slow_accelration; read speed < $speed_path; ydotool mousemove -x $speed  -y $speed"
    bindsym --release Shift+Period exec echo $min_slow > $speed_path
    bindsym Shift+y exec "$accelrate_script $max_slow $slow_accelration; read speed < $speed_path; ydotool mousemove -x -$speed  -y -$speed"
    bindsym --release Shift+y exec echo $min_slow > $speed_path
    bindsym Shift+o exec "$accelrate_script $max_slow $slow_accelration; read speed < $speed_path; ydotool mousemove -x $speed  -y -$speed"
    bindsym --release Shift+o exec echo $min_slow > $speed_path

    ## Fast movements
    bindsym Ctrl+h exec "$accelrate_script $max_fast $fast_accelration; read speed < $speed_path; ydotool mousemove -x -$speed  -y 0"
    bindsym --release Ctrl+h exec echo $min_fast > $speed_path
    bindsym Ctrl+j exec "$accelrate_script $max_fast $fast_accelration; read speed < $speed_path; ydotool mousemove -x 0 -y $speed"
    bindsym --release Ctrl+j exec echo $min_fast > $speed_path
    bindsym Ctrl+k exec "$accelrate_script $max_fast $fast_accelration; read speed < $speed_path; ydotool mousemove -x 0 -y -$speed"
    bindsym --release Ctrl+k exec echo $min_fast > $speed_path
    bindsym Ctrl+l exec "$accelrate_script $max_fast $fast_accelration; read speed < $speed_path; ydotool mousemove -x $speed  -y 0"
    bindsym --release Ctrl+l exec echo $min_fast > $speed_path
    bindsym Ctrl+n exec "$accelrate_script $max_fast $fast_accelration; read speed < $speed_path; ydotool mousemove -x -$speed  -y $speed"
    bindsym --release Ctrl+n exec echo $min_fast > $speed_path
    bindsym Ctrl+Period exec "$accelrate_script $max_fast $fast_accelration; read speed < $speed_path; ydotool mousemove -x $speed  -y $speed"
    bindsym --release Ctrl+Period exec echo $min_fast > $speed_path
    bindsym Ctrl+y exec "$accelrate_script $max_fast $fast_accelration; read speed < $speed_path; ydotool mousemove -x -$speed  -y -$speed"
    bindsym --release Ctrl+y exec echo $min_fast > $speed_path
    bindsym Ctrl+o exec "$accelrate_script $max_fast $fast_accelration; read speed < $speed_path; ydotool mousemove -x $speed  -y -$speed"
    bindsym --release Ctrl+o exec echo $min_fast > $speed_path

    ## Scrolling
    bindsym $mod+h exec ydotool mousemove --wheel -x 1 -y 0
    bindsym $mod+j exec ydotool mousemove --wheel -x 0 -y -1
    bindsym $mod+k exec ydotool mousemove --wheel -x 0 -y 1
    bindsym $mod+l exec ydotool mousemove --wheel -x -1 -y 0

}

## repeat_delay of keys is modified cause you don't want delay in moving your mouse
bindsym $mod+m input "type:keyboard" repeat_delay 50, mode " mouse"

accelrate.sh

#!/bin/sh

if [[ -z $1 ]]; then
    echo No max_speed argument provided > /tmp/sway-log/accelrate.log
    exit 1
fi

if [[ -z $2 ]]; then
    echo No accelration argument provided >> /tmp/sway-log/accelrate.log
    exit 1
fi

speed_path=/home/taham/.config/sway/data/speed
max_speed=$1
accelration=$2
read current_speed < $speed_path

if [[ $current_speed -ge $max_speed ]]; then
    echo $max_speed > $speed_path # current speed can grow greater than max speed
    exit 0
fi

new_speed=$(( $current_speed + $accelration))
echo $new_speed > /home/taham/.config/sway/data/speed
